    Shale Shaker Screen Viberation Motor 2*0.75Kw Viberation Amplitude 3.92~5.62 mm

    Ask Lasest Price
    Brand Name : ATO
    Payment Terms : L/C, T/T
    Supply Ability : 10 [PIECES PER MONTH
    Delivery Time : 10-15 WORK DAYS
    • Product Details
    • Company Profile

    Shale Shaker Screen Viberation Motor 2*0.75Kw Viberation Amplitude 3.92~5.62 mm

    Shale Shaker Screen Viberation Motor 2*0.75Kw Viberation Amplitude 3.92~5.62 mm


    Descriptions of Shale Shaker Screen Viberation Motor 2*0.75Kw Viberation Amplitude 3.92~5.62 mm:


    We can design double shakers and truplicate shakers on single skid according to client's special requirements and also supply relevant connection manifold according to xurrent industry situation, we provide both third reneration liner motion shale shaker and fourth generation balanced elliptical shale shaker.
    Shale shaker absorbed advanced tech at home and abroad, complete series shale shaker can meet custimers variablr demand. Client feedback proved the advantages for this kind of shale shaker: high G-force, wide screen area, compressed structure, cost-effective, etc.


    Specifications :


    ModelZS752E-DMZS703F-HBZS703E-DZZS954E-HBZS706E-HB
    Viberation ModelLiner MotionLiner MotionLiner MotionLiner MotionLiner Motion
    Capacity45 m3 / h
    (200GPM)
    120 m3 / h
    (528GPM)
    140 m3 / h
    (616GPM)
    120 m3 / h
    (528GPM)
    120 m3 / h
    (528GPM)
    Viberation Motor2*0.75Kw2*1.72Kw2*1.72Kw2*1.72Kw2*1.94Kw
    Screen Qty2 Panels3 Panels3 Panels4 Panels6 Panels
    Screen Area1.35 m22.63 m22.63 m22.7 m2Upper layer
    2.0 m3
    Screen Size(mm)750*900700*1250700*1250585*1165Upper layer
    Adjustable G ForceLess than 7.1 GLess than 7.5 GLess than 7.5 GLess than 7.5 GLess than 7.5 G
    Viberation Amplitude3.92~5.62 mm4.14~5.96 mm4.14~5.96 mm4.14~5.96 mm4.14~5.96 mm
    Deck Angle Range20-1~+50-1~+50-1~+50-1~+50
    Weir Height710 mm735 mm1042 mm735 mm895 mm
    Ex StandardExd BT4 / IEC Ex / ATEXExd BT4 / IEC Ex / ATEXExd BT4 / IEC Ex / ATEXExd BT4 / IEC Ex / ATEXExd BT4 / IEC Ex / ATEX
    Weight910 kg1550 kg1700 kg1600 kg1870 kg
    Dimension(mm)1670*1730*10702370*1940*12702500*1980*14801940*1940*12702730*2030*1430
