SCP SP Series Centrifugal Pump

The SCP SP Series Centrifugal Pump are specially designed for oil field applications. It features high pressure, and large displacement. These features make this series of pumps ideal for use in fracturing, cementing, and blending operation, as well as, pumping in drilling operations.

Series:

Major Features:

1. Mechanical seals and oil seals for option by users;

2. Speed can be up to 3,500 RPM, to meet the need of large displacement;

3. Rigid support, made of casting, has an excellent shockproof function;

4. Designed to meet SAE “C” and SAE “D” hydraulic motor input size, or come with single keyed shaft for mounting;

5. The hydraulic motor is connected to the pump are through splines, to significantly eliminate an alignment error;

6. The volute can be rotated to match various discharge /mounting configurations;

7. Impellers with different diameters are available according to different pressure, displacement and power requirements.
