    RMKP PZ-8 Mud Pump Drilling Equipment 750HP Input Power Rating API 7K

    Ask Lasest Price
    Brand Name : ATO
    Model Number : PZ-8
    Certification : API
    Payment Terms : L/C, T/T
    Supply Ability : 10 PIECES PER MONTH
    Delivery Time : 10-15 DAYS
    • Product Details
    • Company Profile

    RMKP PZ-8 Mud Pump Drilling Equipment 750HP Input Power Rating API 7K

    RMKP API 7K PZ-8 Mud Pump


    Input power rating (KW) 559 (750HP)
    Rated pump speed (RPM) 145
    Stroke Length (mm) 203 (8”)
    Gear ratio 4.5
    Rated speed of transmission shaft (RPM) 652
    Max. working pressure (Kg/sq.cm) 352 (5000PSI)
    Valve size (API) 7#
    Max. liner diameter (mm) Φ7”
    Max. displacement (GPM) 580
    Max. liner pressure (Kg/sq.cm) 140 (1996PSI)
    Diameter of suction pipe (mm) 254 (10”)
    Diameter of discharge pipe (mm) 100 (4”)
    Overall dimensions 3650×2460×2520 mm
    Weight ( without dampener and joint atc) 10000kg
    Weight (with dampener and joint atc) 12200kg
